Civil Site Design v20

Civil Site Design v20 is one of the biggest releases for the platform, with improvements to the existing tools and packed with new developments.

Faster, Easier, Smarter

Civil Site Design provides you with highly efficient and simple-to-use civil design tools for road network design, highways, road reconstruction, site grading, surface creation, stormwater, sewer and pipeline design.

Experience the Power
of Civil Site Design

We regularly host webinars covering the fundamentals and advanced features of Civil Site Design, as well as other civil and survey software.

Civil Design Software Shouldn't Cost the Earth

Civil Site Design provides you with highly efficient and simple-to-use civil design tools for road network design, highways, road reconstruction, site grading, surface creation, stormwater, sewer and pipeline design.

previous arrow
next arrow
Slider

Land Development

Civil Site Design software is used for Land Subdivision and Development, with Fast, Efficient and dynamic Design of intersections, kerb returns, cul-de-sacs and knuckles. Include roundabouts with ease. Have multiple design windows open at once. As you move a road string, watch all sections update, intersections update and surface rebuild. Get volumes without effort. Click button outputs to long and cross section sheets and point setout.

Road Reconstruction

Civil Site Design software is used for Road Resurfacing, Reconstruction and Repair. Design your sections to account for all constraints – with tools to match to surfaces, other strings, continue crossfalls, match to horizontal constraints, and conditionally remove sections. Automate your string vertical design based on minimum pavement thickness and match to surface. Build your own models from multiple strings.

Site Grading

Civil Site Design software is used for Site Grading and Land Levelling, using fast volume outputs. Grade parcels, building pads, detention basins, and wetlands. Create gradings directly from polylines and cross section assemblies, with simple corner cleanup tools applied at corners. Apply changing batter slopes, and apply alignment controls. Design using a graphical profile design window and/or Grid View design window.

Highway Design

Civil Site Design software is used for Freeway, Highway and Road Engineering, Design, Planning and Construction. It is a proven performer on large scale road designs and models. With this dynamic and flexible software, you are able to automate traditional intersections and model complex interchanges, via a hybrid assembly and string based approach. You will get lightning-fast speed as you make design changes.

Stormwater & Sewer Pipe Design

Civil Site Design software is used for Stormwater, Sewer and Drainage Pipe Design and Layout. Design an underground Pipe System Network using a surface or in context with road designs, including Stormwater Design for Pipe Sizing, and Sewer Design house connection controls for establishing pipe invert levels. Use Automated rules for minimum cover and slope requirements. Quickly identify and resolve any conflicting services.

Surface Modelling

Civil Site Design software is used for Surface Object and Data Modelling and Analysis. The TIN Surface modelling tools put the power of design in your hands, combining 3D faces, 3D polylines, AutoCAD points and point files. This is a rapid display engine showing contours, labelling and analysis outputs in the drawing. Generate surface analysis tables and export to Civil 3D Surfaces. Easily generate volume reports and stack surfaces.
